OSRAM BT Control | Applications and settings
32
5.1.3.3 Out-of-the-box features (no app for configuration needed!)
Manual control via two directly connected pushbuttons
Button 1:
— Short press: On/off
— Long press: Dim up/down
Button 2 (with resistor):
— Short press: Scene toggle
— Long press: Tune cold/warm (Tunable White)
Control via smartphone with the OSRAM BT Control App
— By connecting the Control App and synchronizing the
RTC (real-time clock) in the DALI ECO BT RTC, the user
automatically starts the HCL function, which is
based on a pre-defined light curve.
— The user can switch and dim the light via smartphone.
— The user can tune the light via smartphone (Tunable White).
— The user can set a password to limit access.
5.1.3.4 Additional configuration options via the OSRAM BT Config App
The controller can be configured via smartphone with the OSRAM BT Config App.
Important note:
After powering up the controller, it can be configured with the BT Config App for two hours only (as long as no admin
password is stored). After the two-hour delay time has expired, connecting to the controller with the BT Config App is
blocked. The timer can be reset by power-cycling the controller. When an admin password is set, the access to the con-
troller will no longer expire.
The following features are a selection of the most popular project-specific adaptations. There are also many additional
settings which can be looked up in the app.
For using the HCL function, the BT Config App configuration
is not mandatory, but enables more flexibility to adapt the
behavior to the requirements of the customer.
5.1.3.5 Password protection
Please see 5.1.1.5: Password protection
