OSRAM BT Control | Applications and settings
43
Activation of semi-automatic mode
1. Open the main menu.
2. Open “Current configuration”.
3. Open “Motion detection”.
4. Move the Automatically Switch
On” slider to off.
The presence sensor will not switch
on the light automatically while detecting
presence, the light needs to be switched
on manually via the pushbutton.
5.2.3.6 Activation of semi-automatic mode
(manually on, automatically off)
5.2.3.7 Grouping
According to the classroom requirements, the luminaires
need to be grouped to realize the four different light groups.
Group the luminaires
1. Open the main menu.
2. Open “Grouping” in the main
menu.
3. Start the addressing procedure by
selecting “Activate Grouping”.
4. All found LED drivers will be listed
and automatically assigned to group 1.
After selecting a device, the connected
luminaire starts flashing.
5. After selecting the group number,
the number changes 1-2-3-4-1 …, as
up to four groups can be configured.
Group 1 = Window row light
Group 2 = Center row light
Group 3 = Inner row light
Group 4 = Presentation board light
2
1
3
2
1
3
4
5
