1 List box Display 8 Data Items.
CH: Index of Channel.
Data Item: name of each Data Item.
Value: sensor values of each Data Item.
Unit: units of each Data Item.
2 File Name Display a lename.
When ‘Use Date/Time’ is displayed, the lename
is created by date and time before start recording.
(A lename will be given such as ‘LOG2007_
Jan_01_12_00_00.csv’)
3 Record Time Display a record time.
If the record time is ’00:00:00’, it will works as
‘ManualStop Mode’. The recording will be continued
till the Stopbutton is clicked.
4 Channel Display a selected trigger channel.
If there is no trigger, blank will be displayed.
5 Low Display the limit value of low-level trigger.
When sensor value of the Data Item becomes less
than the limit value, the recording will be started.
6 High Display the limit value of high-level trigger.
When sensor value of the Data Item becomes more
equal than the limit value, the recording will be star
ted.
7 Time Display an elapsed time of the recording.
8 State Display three recording state.
1. Ready Before click a start button.
2. Waiting Waiting a trigger.
3. Recording Recording sensor values.
9 [Toolbar] View Setting button Show Select Data Items Dialog.
10[Toolbar] Recording Setting button Show Data Recording Setting Dialog.
11 [Start] button Start recording sensor values. If there is a trigger,
‘Waiting’ is displayed. After thetrigger is taken, ‘Re
cording’ will be displayed and therecoding will be
started.
12 [Stop] button Stop recording or waiting.
13 When this screen is displayed When the ECU is not connected, the ECU connec
tionwill be started. If failed to connect to the ECU, the
Message 7 will be shown.
