OTTO 1 00 Fast Charger OMM- 000037 REV. H
23
© Clearpath Robotics Inc. 2020. All rights reserved. CLEARPATH and OTTO are trademarks of Clearpath Robotics Inc. All other product and company names listed are trademarks
or trade names of their respective companies. The information contained in these documents is the Confidential and/or Proprietary property of Clearpath Robotics Inc. and may not
be duplicated, reproduced or further disclosed without the express written approval of Clearpath Robotics Inc.
7 SYSTEM OVERVIEW
This section provides an overview of the important elements of the charger system.
Caution
Take note of the different charger configurations, dependent on the model of OTTO 100 self-
driving vehicle (SDV) to be charged.
7.1 System Specifications
Table 4 Charger System Specifications
200-240 VAC
(V2.2: 017275)
(V2.4: 018053)
380-440
VAC
(V2.2:
015235)
(V2.4:
018054)
480 VAC
(V2.2: 014445)
(V2.4: 018044)
600 VAC
(V2.2: 014446)
(V2.4: 018052)
Market Usage
Japan 3-phase
Europe 3-
phase
North America
480VAC 3-phase
North America
600VAC 3-phase
Size
Dock Footprint (L x W)
1170 x 838 mm
(46 x 33 in)
1170 x 838
mm
(46 x 33 in)
1170 x 838 mm
(46 x 33 in)
1170 x 838 mm
(46 x 33 in)
Charger Electronic Unit
Footprint (L x W)
260 x 385 mm
(10.24 x 15.16
in)
260 x 385
mm
(10.24 x
15.16 in)
260 x 385 mm
(10.24 x 15.16 in)
270 x 560 mm
(10.63 x 22.17 in)
