mounting holes on the Charger Electronic Unit.
5. Remove the Charger Electronic Unit and install anchors and/or fasteners to the wall. Re-hang the
charger and secure the Charger Electronic Unit to the wall using the mounting holes with
appropriate fasteners.
For mounting on charger stands or battery racks, the available stands can be used, or frequently
customers use 2 sections “uni-strut” rails mounted on the stand or rack to mount to the
mounting holes on the rear of the charger. Longer sections of uni-strut can be used to mount
several chargers side by side. Always be sure to allow 12 in between chargers.
Pinch/Crush
Objects can be pinched between the Charge Dock and its tower(s) during installation. Take
care while installing the Charge Dock to keep fingers clear of the joint between the tower(s)
and the Charge Dock.
Impact/Crushing
Objects can be crushed in the space between contact assemblies and the covers during
installation. Always be aware of objects which may be at risk within the operating environment.
10.2.1 Required Materials
• Charge Dock base assembly
• Charge Dock towers (left and right)
• Signal cable harness
• Cable sleeving
• Zip-ties
• Threaded concrete anchor kit 3/8 in
Be sure to use the threaded concrete anchors provided with the charger.
