• Washers
• Precision shims for leveling Charge Dock, if required
• ICD-000046 - Navigation and Docking Requirements - OTTO 100
• Nameplate
• 4 x concrete self-tapping screws 1/4 in x 2 3/4 in
• Hammer-drill
• 3/8 in concrete drill bit
• 5/32 in concrete drill bit
• Hammer
• 14 mm deep socket and associated ratchet
• Torque wrench that can torque to at least 26 Nm and minimum 24 Nm
• Appropriate socket attachments to fit the torque wrench to the 14 mm deep socket (0.9 Nm for
small terminal block, 21.5 Nm for bus bar)
• T-20 Torx driver
• Multi-meter
• 10 mm wrench and deep socket (signal wire ring terminal)
• 13 mm wrench and socket (battery power wire)
• 17 mm wrench and socket (Charger Tower cover)
• 5 mm Allen key
• Utility knife
10.2.2 Charge Dock Location Selection
Ensure enough empty space exists around the chosen location to meet the navigational requirements
outlined in ICD-000046 - Navigation and Docking Requirements - OTTO 100.
Select an area with as flat a floor grade as possible, free of large cracks or bumps.
