11 BASIC USAGE
This section describes the operation of the charger system.
11.1 Charger Electronic Unit
The charger has been shipped pre-configured and does not require configuration. Each Charger Electronic
Unit displays charger status and output current. The green LED panel should be illuminated at all times to
indicate the charger is powered.
For peak power, current, and voltage drop specifications, see the Charger Electronic Unit Operating
Instructions - available on help.ottomotors.com.
11.2 Starting Up
Caution
Prior to starting up the charger, the Charge Dock must be clear of obstructions.
To initiate power to the charger system:
1. Install the charger.
2. The LCD panel on the Charger Electronic Unit should read “Connect Battery” and a blue LED
should be illuminated near the keypad. The system is now ready to use.
