MATE3 Screens
70 900-0009-01-00 Rev C
Data Log File Format
Information generated by this function will be saved on the SD card in a generic .csv file format, which
can be read by most spreadsheet programs.
Data Logging example:
Figure 79 Data Log Example for the Charge Controller
Date AH Kwh
Max
Amps
Max
Watts
Absorb
Time
Float
Time
Min
Battery V
Max
Battery V
MAX
VOC
6/13/11 0 0 1.2 29 0:00 0:00 24.1 29.1 122
6/12/11 38 0.9 5.5 143 0:00 0:00 24.1 29 122
6/11/11 32 0.8 5.6 144 0:00 0:00 24.1 28.7 120
6/10/11 9 0.2 3.5 89 0:00 0:00 24.1 28.9 120
6/09/11 31 0.7 6.8 173 0:00 0:00 24.1 28.8 119
NOTE: This header line is NOT included in the download.
