Panel Operation
input the desired value and choose the unit.
Set the high level
Press Amplitude/High Level softkey to confirm whether the High Level menu
item is highlighted; if not, press Amplitude/High Level softkey to switch to
High Level. In Parameter 2 of Figure 5- 2, a cursor appears in the parameter
value of high level. Turn the knob to change the value directly, or use the
numeric keypad to input the desired value and choose the unit.
Set the low level
Press Offset/Low Level softkey to confirm whether the Low Level menu item
is highlighted; if not, press Offset/Low Level softkey to switch to Low Level.
In Parameter 3 of Figure 5- 2, a cursor appears in the parameter value of low
level. Turn the knob to change the value directly, or use the numeric keypad
to input the desired value and choose the unit.
Set the Phase
Press Phase softkey to confirm whether the Phase menu item is highlighted; if
not, press Phase softkey to switch to Phase.In Parameter 4 of Figure 5- 2, a
cursor appears in the parameter value of Phase. Turn the knob to change the
value directly, or use the numeric keypad to input the desired value and
choose the unit.
Output Square Wave
Press , the screen displays the user interface of the square wave. The
Square waveform parameters can be set by operating the Square setting
menu on the right.
The square wave menu includes: Frequency/Period, Amplitude/High Level,
Offset/Low Level, and Phase.
To set the Frequency/Period, Amplitude/High Level, Offset/Low Level, Phase,
please refer to Output Sine Wave on page 7.
