Owon DGE1000 Series User Manual

4
.
Quick Start
4
4. Quick Start
Front Panel Overview
Figure 4- 1 Front Panel Overview
1
LCD
Display the user interface.
2
Menu
selection
keys
Includes 5 keys to activate the corresponding menu.
3
Operation
keys
Mode
：
output the modulated waveform.
4
Knob
Change the currently selected value, also used to select
the arbitrary waveform types and arb data file name.
5
Direction key
Move the cursor of the selected parameter.
6
Utility
set the utility function.
7
Power button
Turn on/off the waveform generator.
8
Number
keypad
Input the parameter.
9
Output
terminal
Output channel signal.
