Page #38 background imageLoading...
Page #38 background image
5
.
Panel Operation
33
(1) Press the front panel Utility function key then press System softkey.
(2) Press the USB Dev softkey to toggle between PC and USBTMC.
PC: This is the internal communication protocol. Select this option
when connecting to the Waveform Editor software via the USB Device
interface.
USBTMC: Select this option when you need to use the USBTMC
communication protocol standard.
Restore to the factory setting
(1) Press the front panel Utility function key, select System softkey, then
press the NextPage softkey.
(2) Press the Factory Set softkey, and then press the Ok softkey to restore
the generator to the factory default settings.
The factory default settings
Output Configuration
Signal output switch
OFF
Function
Sine
Frequency
1.000 000 kHz
Amplitude/Offset
1.000 Vpp / 0 mV
Basic Waveform
Frequency
1.000 000 kHz
Period
1.000 000 ms
Amplitude
1.000 Vpp
Offset
0 mV
High Level
500 mV
Low Level
-500 mV
Phase
Ramp Wave Symmetry
50.00%
Pulse Width
200.000 us
Pulse Duty Cycle
20.00%
Pulse Rising Time
1.953 us
Pulse Falling Time
1.953 us
Build-in Wave
X^2
Modulation Waveform
Modulation type
AM
