Owon DGE1000 Series User Manual

8
.
Specification
40
Phase noise
Typical (0dBm, 10kHz offset)
10MHz: ≤-110dBc/Hz
Square
Rise/fall time
< 20ns
Jitter (rms), typical (1Vpp,
50Ω)
200ps + 30ppm
Overshoot
< 5%
Ramp
Linearity
< 1% of peak output
(typical 1 kHz, 1 Vpp, symmetry 50%)
Symmetry
0% to 100%
Pulse
Period
DGE1030
67 ns to 1 Ms
DGE1060
50 ns to 1 Ms
Pulse Width
≥ 24ns
Rise and fall time
≥ 15ns
Overshoot
< 5%
Jitter (rms), typical (1Vpp,
50Ω)
200ps + 30ppm
Noise
Types
Gaussian white noise
Bandwidth (-3dB)
20 M
Arbiratry wave
Bandwidth
10M
Waveform length
2 to 8K points
Sampling rate
DGE1030
125Ma/s
DGE1060
300Ma/s
Amplitude accuracy
14 bits
Modulation Characteristics
Modulation Characteristics
Modulation Type
AM, FM, PM, FSK
AM
Carrier
Sine wave, square wave, ramp wave, arbitrary wave (except
DC)
Modulated signal
source
Internal
Internal modulation
waveform
Sine wave, square wave, ramp wave, white noise
Internal amplitude
modulation frequency
2 mHz to 100 kHz
Depth
0.0% to 100.0%
FM
