Owon DGE1000 Series User Manual

8
.
Specification
38
8. Specification
All technical specifications are guaranteed when the following conditions are
met, unless otherwise stated.
 The signal generator must be operated continuously for more than 30
minutes at the specified operating temperature (20°C to 30°C) to meet
these specifications；
 The signal generator is in the calibration internal and has performed a
self-calibration.
In addition to the specifications marked with the word "Typical", the
specifications used are guaranteed.
Waveforms
Waveforms
Bandwidth
DGE1030
30 MHz
DGE1060
60 MHz
Sample Rate
DGE1030
125MSa/s
DGE1060
300MSa/s
Vertical Resolution
14 bits
Channel
1
Standard
Waveforms
Sine wave, square wave, ramp wave, pulse wave, noise
Arbitrary
Waveforms
Sinc, exponential rise, exponential decline, electrocardiogram,
Gaussian, semi-positive, Lorentz, dual audio, DC voltage totaling
more than 160 kinds
Frequency Characteristics
Frequency Characteristics (Frequency resolution to 1 μHz)
Sine wave
DGE1030
1 μHz ~ 30MHz
DGE1060
1 μHz ~ 60MHz
Square wave
DGE1030
1 μHz ~ 15MHz
DGE1060
1 μHz ~ 20MHz
Pulse wave
DGE1030
1 μHz ~ 15MHz
DGE1060
1 μHz ~ 20MHz
Ramp wave
DGE1030
1 μHz - 1 MHz
DGE1060
1 μHz - 2 MHz
Noise wave (-3 dB)
20 MHz BW（AWGN）
Arbitrary wave
1 μHz - 10 MHz
Frequency
resolution
1 μHz or 7 significant figures
Frequency stability
±30 ppm at 0±40℃
