5) [View]
Holds and displays current trace for observation. The trace register
is not updated as the analyzer sweeps.
6) [Blank]
Clear the trace on screen. The selected trace register stores the
trace data, and will not be updated as the analyzer sweeps.
7) [Return]
Return to the upper-level menu.
5.7.3 [Operations>]
Enter the trace math submenu.
1) [1 ↔ 2]
Exchange the trace register 1 data with the trace register 2, and
place them in display mode.
2) [2-DL → 2]
Subtracts the display line value from the trace register 2. This
function executes once when activated. Press [2-DL → 2] again to
execute it the second time. When this function activated, the
display line will also be activated.
3) [2 ↔ 3]
Exchange the trace register 2 data with the trace register 3, and
place them in display mode.
4) [1 → 3]
Change the trace register 1 data to the trace register 3, and place
the trace register 3 data in display mode.
5) [2 → 3]
Change the trace register 2 data to the trace register 3, and place
the trace register 3 data in display mode.
6) [Return]
Return to the upper-level menu.
5.8 【Detector】 hardkey
Key access:
Press Shift key, then Detector hardkey (8 in numeric
keypad).
