Owon HSA1000 Series User Manual

4.Quick Start
9
4.4 Front Panel Overview
10
1 3 4
6
5
7
8
9
2
Figure 4-1 Front panel
NO.
Description
①
LCD touchscreen.
②
Light Sensor: Adjusts the screen backlight according to
the environmental light. This state can be specified in
【Display】→ [Brightness].
③
Power key: Long push to turn on the analyzer, push to turn
on/off the LCD display, long push to turn off the analyzer.
④
Preset key: Resets the analyzer to a known state.
This state can be specified in 【System】→
[PowerOn/Preset>] → [Preset>].
⑤
Arrow keys.
⑥
Rotary knob.
