 Extension sensor test
Follow these instructions to check the extension sensor:
1) put the telescopic completely in
2) check from the display the extension values (Fig. 5.21 - D). Both must be around 0%.
3) extend completely the telescopic
4) check from the display the extension values (Fig. 5.21 - D). Both must be aroung 100%.
If the difference betweeen the sensor value and the reference is less than the tollerance, the
sensor is working fi ne.
 Boom inclinometer check
Follow these instructions to check the boom inclinometer:
1) Put an additional bubble on the boom and move it to 0° (checking the bubble)
2) now check the angle boom values from the display (Fig. 5.22 - E).
Both must be around the reference value (0°).
If the difference betweeen the sensor value and the reference is less than the tollerance, the
sensor is working fi ne.
 Basket load cell check
Follow these instructions to check the basket load cell:
1) remove all the additional loads from the basket (it muste be empty).
2) now check the basket weight values from the display (Fig. 5.21 - F).
Both must be around the reference value (0 Kg).
If the difference betweeen the sensor value and the reference is less than the tollerance, the
sensor is working fi ne.
!
WARNING!
Inform the responsible personnel of any problem encountered.
