1. GENERAL CHARACTERISTICS
1.1. INTRODUCTION
“Ragno” is the most proper aerial access platforms for aerial work and diffi cult access
thanks to its stowed dimensions and light weight.
One of the “Ragno” peculiarities is the stabiliser set-up possibility to be rotated and
articulated independently, always granting the working area automatic limiting system
in safety conditions.
Powered by standard dual power: no-noise thermic power pack for robust external wor-
king and electric motor(s) for quiet and smoke-free indoor operations, it solves any
issue linked to environment.
The machine is available in rubber-tracked crawler version particularly fi t for irregular
grounds, being capable of climbing steps or steep slopes. It is equipped with a wide ran-
ge of optional equipments which meet every application need.
The platform is not electrically isolated but it is being designed to operate outdoor.
1.2. DESCRIPTION
“Ragno” unit mainly consists of a frame with 4 articulated stabilizing legs, hydraulically
controlled, a turntable slewing on a ball bearing ring.
Steel made multi-telescopic boom is hinged to the turntable and it supports the aerial cage,
with an hydraulically articulating jib. All movements are actuated by hydraulic cylinders, or
hydraulic motors
The machine is mounted on rubber tracks, completely integrated with the supporting
frame.
Three power packs are mounted: el.motor 220V, el.motor 380V and no-noise diesel
engine, all driving the platform movements alternatively and both source are able to
the boom mouvements and travelling. The machine has two complementary control
panels. One in the cage, which is used for aerial work.
The ground control panel is used for the travelling and stabilizer positioning, and, if
allowed, the boom mouvements, as well as the emergency operations.
1.3. DIRECTIVE AND RULES
2006/42/CE Directive indicates the conditions to deliver the machine in EU market.
The machine supplied by Palazzani Industrie is a machine complying one of the ma-
chines category listed in the Directive attachment IV. Palazzani applies the procedure
of conformity evaluation with CE exam method as per attachment IX, to comply with
the conformity.
To comply with the conformity of the machine to the Directive dispositions, Palazza-
ni fulfi ls the risks analysis to verify the respect of safety and health essential subjects
indicated in the Directive, further than performing the tests and check required in the
applied rules, before delivering the machine.
