1.5. DIMENSIONS AND PERFORMANCES
Machine in transfer position
Min. height 2280 mm
Lenght 8520 mm
Width (without cage) 1350 mm
Total weight 10900 kg
Max pressure on the ground of track 0.57 kg/cm
2
Max. working height 43 m
Max. cage fl oor height 41 m
Max. outreach (basket border) 17.5 m
Max cage working load 230 kg (330kg optional)
Max. horizontal pull 400 N
Aerial cage dimensions ( A x B ) 2.4 x 0.7 m - h 1.1 m.
Min steering radius 5700 mm
Max. selfpropelling speed 2.25 km/h
Superable slope 40 %
Max. lateral slope (with tracks) 15 %
Turntable slewing E330° (360° continui optional)
Cage rotation 90° + 80°
Hydr. system working pressure with diesel engine 220 bar
Hydr. system working pressure with el. motor 180 bar
Max. admitted wind speed 45 km/h
Max. admitted chassis slope 2°
Technical data - time
DIESEL
Stabilizing legs lowering (to fl oor touch) 40 sec.
Stabilizing legs raising 25 sec.
Boom lifting (completely retracted) 60 sec.
Boom lowering (completely extended) 60 sec.
Telescopic boom extension 100 sec.
Telescopic boom return 80 sec.
Jib lifting 60 sec.
Jib lowering 60 sec.
Right-left turning (1 turn) 220 sec.
Transfer speed:
10 m slow 120 sec.
10 m fast 15 sec.
