Pag. 4OM1070_GB
Time are considered with empty cage, worm oil and max joystick activation.
A 10% tolerance on this value is acceptable. Time and dimensions are indicative and
Palazzani SpA may change the value for internal causes.
Main mechanic components
Tracks type: SAMPIERANA PT70G43
Breakes: negative and automatic, with hydraulic releasin
Cage levelling reductor: PALAZZANI
Turntable rotation motoreductor: DINAMIC OIL RE242TS-MD-MLG 200
Main hydraulic components
Diesel engine pump PLP 20.16/20.11,2D
220V el.motor pump PLP 20.4D
Turntable slewing device ATTUATORE MOVECO 168°
Proportional electrodistributor BOSH REXROTH
Overcenter valves on pistons OIL CONTROL/ HAWE
Filters IN SENT WITH FULL CAPACITY
Filtering 25 micron
Oils: hydraulic system BP ENERGOL HLP HM 46
reducers IP PONTIAX FZG85W/90
diesel engine See manufacturer book
Grase IP AUTO GREASE MP
Hydraulic oil tank 150 liters
!
ATTENTION
For fi lling-up, it is recommended to use the above
specifi ed oil types exclusively - in case of oils with corresponding
characteristics, it is advisable to make a complete change.
Main electric components
Electrical motors 2.2 kW 220 V a.c.
Generator (optional) 5 kW 230 V a.c.
Battery n° 2 100 A/h 24V
Battery charger 220 V ac - 24 V dc - 6 A
Radio control Hetronic
Engine diesel intake
Brand PERKINS 404C-22
Fuel diesel
Regimen 2600 rpm.
Transmission neutral
