31
Installing lifting mechanism
7.1.6 Installing the hydraulic unit (option)
The installation of your hydraulic unit depends on the selected type.
Three types are available:
• Slide-in unit
• Turning unit
• Box unit
• Universal unit
The hydraulic unit is normally premounted by PALFINGER Tail
Lifts. On request, you can also obtain a box unit with long cables
and hoses. You can then mount this box unit at any position under
the vehicle. If the cables and hoses are too long, you must bundle
them and fix them under the vehicle.
7.1.7 Removing the installation aids
Remove the pins between the control rods and the installation
aids and carefully fold the control rods down.
Release the screw clamps with which the installation aids are
fixed to the vehicle chassis.
Remove the installation aids from the vehicle chassis.
ATTENTION
Risk of damage to components!
As there is still too little oil in the lift cylinders, the control rods can swing out in an
uncontrolled fashion, thus damaging the lifting mechanism.
Carefully fold down the control rods.
