30
Installing lifting mechanism
Mount the lifting mechanism as described in section “Installing
lifting mechanism” frompage 23.
Then precisely align the console plates (2) with respect to height
and width to the chassis.
Fix the console plates to the vehicle chassis and tighten the hex.
nuts (5).
Optional: Screw the locking clamps (7) by means of the hex.
screw and nut to the stand tube (1).
Note the following tightening torques.
The bolts must be regularly retightened regularly:
• after 3 weeks in operation
• after 3 months in operation
• check and if necessary retighten half-yearly
If the battery cable is not directly connected to the battery and the
ground runs over the vehicle chassis, it may be necessary to fabri-
cate a ground cable from the delivered cable lugs and protective
caps.
Cut off the required length of cable from the supplied battery
cable.
Keep the ground cable (8) as short as possible and attach it to the
ground screw provided on the stand tube.
Before lifting the platform, make sure that the solenoid valves on
the lift cylinder can move freely at the U-section (6) of the bolted
console. Otherwise you must turn the coil on the solenoid valve
through 90°.
Bolts Tightening torque
Bolt M20x1.5 - St10.9 400 Nm
Bolt M14x1.5 - St10.9 190 Nm
Bolt M10 - St8.8 50 Nm
NOTE
Before connecting the ground cable, find out from the vehicle maker whether this is
possible.
