Operating Instructions
97
4.4 Setting the Motion Detection
The Motion Detection page allows you to adjust the sensitivity of Motion Detection.
Threshold: If the threshold is set low, this function detects nearly all movements.
Sensitivity: If you set sensitivity high, the amplitude of the motion detection bar gets
jumpy.
1. Click [Motion Detection] on the Setup page.
2. Click the Motion Detection bar in Threshold to set the threshold level.
3. Click the Motion Detection bar in Sensitivity to set the sensitivity level.
4. Click [Save] to save the settings.
• Clicking [Cancel] cancels your settings without saving changes.
5. Click [Go to Motion Detection page].
• The Motion Detection page is displayed.
Preview
Display the current threshold and detection level.
• The threshold is the line between the green and red bar.
• The detection level is the line between the dark red and light red color.
• The Threshold and Sensitivity settings are enabled after saving, and
reflected in preview.
Setting Description
Threshold • Adjusts the threshold for Motion Detection. As the value is
set lower, the sensor will detect motions of smaller
changes.
Sensitivity • Adjusts the sensitivity for Motion Detection. As the value is
set higher, the amplitude of the Motion Detection bar will
become greater.
