Panasonic DMR-ES35VP

17 Replacement Parts List
Notes:
*Important safety notice:
Components identified by
mark have special
characteristics important for safety.
Furthermore, special parts which have purposes of fire-
retardant (resistors), high-quality sound (capacitors), low-
noise (resistors), etc. are used.
When replacing any of components, be sure to use only
manufactures specified parts shown in the parts list.
*Warning: This product uses a laser diode. Refer to caution
statements.
*Capacity values are in microfarads (µF) unless specified
otherwise, P=Pico-farads (pF), F=Farads (F).
*Resistance values are in ohms, unless specified otherwise,
1K=1,000 (OHM), 1M=1,000k (OHM).
*The marking (RTL) indicates the retention time is limited
for this item. After the discontinuation of this assembly in
production, it will no longer be available.
*“(IA)-(IB)”, marks in Remarks indicate languages of
instruction manuals. [(IA): English, (IB): Canadian French]
*Parts indicated with PAVC-CSG in the Remarks column
are supplied by PAVC-CSG.
*All parts except parts indicated with (PAVC-CSG) in the
Remarks column are supplied by PAVCSG.
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
## VEPV0054BT MAIN P.C.B. (RTL)
C2001 ECJ1VC1H330J 50V 33P 1
C2002 F1H0J1050010 6.3V 1U 1
C2003 ECJ1VF1A105Z 10V 1U 1
C2051 F1J0J106A014 6.3V 10U 1
C2052 F1J0J106A014 6.3V 10U 1
C2053 ECEA1CKS100B 16V 10U 1
C2054 F1H1H392A013 50V 3900 1
C2055 F1H1C104A008 16V 0.1U 1
C2099 ECJ1VC1H681J 50V 680P 1
C2501 F1H1C104A008 16V 0.1U 1
C2502 ECA1AAK221XB 10V 220P 1
C2504 F1H1E223A002 25V 0.022U 1
C2505 F1H1E223A002 25V 0.022U 1
C2506 ECJ1VB1A224K 10V 0.22U 1
C2507 F1H1H102A219 50V 1000P 1
C2508 ECJ1VB1H182K 50V 1800P 1
C2509 ECA1CAK220XB 16V 22P 1
C2510 F1H1C104A041 16V 0.1U 1
C2511 F1H1C104A041 16V 0.1U 1
C2512 F1H1C104A041 16V 0.1U 1
C2513 ECJ1VF1A105Z 10V 1U 1
C2515 F1H1H103A220 50V 0.01U 1
C2518 F1H1H103A220 50V 0.01U 1
C2519 F1H1H103A220 50V 0.01U 1
C2551 ECJ1VB1C473K 16V 0.047U 1
C2552 ECJ1VB1C683K 16V 0.068U 1
C2561 ECJ1VB1C683K 16V 0.068U 1
C2562 ECJ1VB1C473K 16V 0.047U 1
C2571 ECA1CAM221XB 16V 220U 1
C3001 ECJ1VC1H151J 50V 150P 1
C3002 F1H1C104A041 16V 0.1U 1
C3003 F1H1C104A041 16V 0.1U 1
C3005 ECJ1VC1H220J 50V 22P 1
C3006 F1H1C104A041 16V 0.1U 1
C3007 F1H0J1050010 6.3V 1U 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
C3008 ECA1HAK4R7XB 50V 4.7 1
C3009 F1H0J1050010 6.3V 1U 1
C3010 F1H0J1050010 6.3V 1U 1
C3011 F1H1C104A041 16V 0.1U 1
C3012 F2A0J470A245 6.3V 47U 1
C3014 F1H1C104A041 16V 0.1U 1
C3015 F1H0J1050010 6.3V 1U 1
C3017 F1H1C104A041 16V 0.1U 1
C3019 F1H1C104A041 16V 0.1U 1
C3020 ECA1HAK3R3XB 50V 3.3 1
C3021 ECA1CAK100XB 16V 10U 1
C3023 F1H1H103A219 50V 0.01U 1
C3024 ECJ1VC1H331J 50V 330P 1
C3025 F1H1H103A220 50V 0.01U 1
C3028 ECA1HAK4R7XB 50V 4.7 1
C3029 ECA1HAKR47XB 50V 47P 1
C3030 F1H1E223A002 25V 0.022U 1
C3031 F1H1C333A071 16V 0.033U 1
C3032 ECA1HAK4R7XB 50V 4.7 1
C3033 F1H1C104A041 16V 0.1U 1
C3034 ECA1HAK2R2XB 50V 2.2U 1
C3035 ECJ1VB1H472K 50V 4700P 1
C3036 ECA0JAK470XB 6.3V 47P 1
C3037 F1H1C104A041 16V 0.1U 1
C3038 ECJ1VC1H040C 50V 40P 1
C3039 ECA1HAK010XB 50V 1U 1
C3040 F1H1H103A220 50V 0.01U 1
C3041 F1H1H103A220 50V 0.01U 1
C3043 F1J0J106A014 6.3V 10U 1
C3044 F1H1C104A041 16V 0.1U 1
C3048 F1H1H103A219 50V 0.01U 1
C3050 F1H1C104A041 16V 0.1U 1
C3051 F1H0J1050010 6.3V 1U 1
C3052 F2A0J470A245 6.3V 47U 1
C3053 F1H1C104A041 16V 0.1U 1
C3074 F1H1C104A041 16V 0.1U 1
C3701 ECA0JAK470XB 6.3V 47P 1
C3702 F1H1C104A041 16V 0.1U 1
C3704 F1H1C104A041 16V 0.1U 1
C3705 F1H1H103A219 50V 0.01U 1
C3706 F1H1C104A041 16V 0.1U 1
C3707 ECEA0JKA220B 6.3V 22U 1
C3709 ECA0JAK470XB 6.3V 47P 1
C3710 F1H1C104A041 16V 0.1U 1
C3711 F1H1H103A220 50V 0.01U 1
C3712 F1H0J1050010 6.3V 1U 1
C3713 F1H0J1050010 6.3V 1U 1
C3714 ECA1CAK100XB 16V 10U 1
C3716 F1H0J1050010 6.3V 1U 1
C3717 F1H0J1050010 6.3V 1U 1
C3718 F1H1C104A041 16V 0.1U 1
C3720 F1H1C104A041 16V 0.1U 1
C3721 F1H0J1050010 6.3V 1U 1
C3722 F1H0J1050010 6.3V 1U 1
C3723 F1H0J1050010 6.3V 1U 1
C3724 F1H1H103A220 50V 0.01U 1
C3725 F1H1H103A220 50V 0.01U 1
C3726 F1H1C104A041 16V 0.1U 1
C3727 ECA0JM471B 6.3V 470U 1
C3728 ECA0JM471B 6.3V 470U 1
C3729 F1H0J1050010 6.3V 1U 1
C3730 ECA0JM471B 6.3V 470U 1
C3731 F1H0J1050010 6.3V 1U 1
C3732 F1H1H103A220 50V 0.01U 1
C3733 ECA0JM471B 6.3V 470U 1
C3734 ECA0JAK470XB 6.3V 47P 1
C3735 ECA0JM471B 6.3V 470U 1
C3744 F1H1H103A220 50V 0.01U 1
C3749 F1H0J1050010 6.3V 1U 1
C3918 F1H1C104A041 16V 0.1U 1
C3919 F1H1H103A220 50V 0.01U 1
C3933 F2A0J471A247 6.3V 470U 1
C4004 ECJ1VB1H182K 50V 1800P 1
109
DMR-ES35VP / DMR-ES35VPC
