SCN PCB - CN713 (DP-C405 Series Only)
CN710-12 +5TV
Home
Position
Sensor
+5V DC Power Supply
CN710-13 nHPSN
Home
Position
Sensor
Home Position Sensor
CN710-14 GND
Home
Position
Sensor
Ground
CN710-15 +5TV
Platen Angle
Sensor
+5V DC Power Supply
CN710-16 nPASN
Platen Angle
Sensor
Platen Angle Sensor
CN710-17 GND
Platen Angle
Sensor
Ground
CN710-18 +5TV
Platen Cover
Sensor
+5V DC Power Supply
CN710-19 nPCSN
Platen Cover
Sensor
Platen Angle Sensor
CN710-20 GND
Platen Cover
Sensor
Ground
SNC PCB
Pin No.
Signal Name Destination Signal Waveform Function
CN713-1 CCDF-LOCK CCD FAN Signal Lock
CN713-2 MGND CCD FAN Power Ground
CN713-3 nCCDF_CNT CCD FAN Control CCD Fan
SNC PCB
Pin No.
Signal Name Destination Signal Waveform Function
+5V
0V
+5V
0V
0V
+5V
0V
+5V
0V
0V
+5V
0V
+5V
0V
0V
+5V
0V
0V
+24V
0V
