DP-C405/C305/C265
PNL1 PCB - CN5
CN4-8 SCN4
PNL2 PCB
CN250-8
Key Scan 4 Signal
CN4-9 SCN5
PNL2 PCB
CN250-7
Key Scan 5 Signal
CN4-10 KIN6
PNL2 PCB
CN250-6
Key Input Signal
CN4-11 KIN5
PNL2 PCB
CN250-5
Key Input Signal
CN4-12 KIN4
PNL2 PCB
CN250-4
Key Input Signal
CN4-13 LED0
PNL2 PCB
CN250-3
LED 0 Activation Signal
CN4-14 KIN3
PNL2 PCB
CN250-2
Key Input Signal
CN4-15 GND
PNL2 PCB
CN250-1
Ground
PNL1 PCB
Pin No.
Signal Name Destination Signal Waveform Function
CN5-1 N.C. No Connection
CN5-2 nFAXRING
SC PCB
CN58-14
Fax Received Detection
Signal
CN5-3 nWAKE
SC PCB
CN58-13
ADF Wake Up Signal
CN5-4 nVCNTON
SC PCB
CN58-12
LED Contrast ON Signal
PNL1 PCB
Pin No.
Signal Name Destination Signal Waveform Function
3.3V
PULSE 0V
3.3V
PULSE 0V
3.3V
PULSE 0V
3.3V
PULSE 0V
3.3V
PULSE 0V
5V
ON
0V
3.3V
PULSE 0V
0V
Received3.3V
0V
Detect3.3V
0V
ON
3.3V
0V
