4.3.2 Voice over Internet Protocol (VoIP) Network
Description
When
a
PBX is connected to another PBX via a private IP network, voice signals are converted into IP packets
and sent over the network. This is known as Voice over IP (VoIP). This PBX uses the H.323 standard for VoIP
communication.
VoIP networks support private network communications using TIE line service.
[Example]
PBX-1
PBX-2
Extn.1000
:
Extn.1999
Extn.2000
:
Extn.2999
V-IPGW
Router
V-IPGW
PBX-3
V-IPGW
Extn.3000
:
Extn.3999
Dials "2999".
Private IP
Network
Router
Router
Telephone Company
TRG 1
TRG 2
398 Feature Guide
4.3.2 Voice over Internet Protocol (VoIP) Network

Panasonic KX-NS1000 Specifications

General

Type	Hybrid IP-PBX
Max Concurrent Calls	256
VoIP Protocols	SIP, H.323
Power Supply	AC 100-240V, 50/60Hz
Maximum Extensions	1, 000
IP Extensions	1000
Operating Temperature	0°C to 40°C
Humidity	10 to 90% (non-condensing)
Max Users	1000
