Ref.
No.
Part No. Part Name & Description Remarks
L405 PSLQR2B2N7S COIL
L406 PSLQR2B2N7S COIL
F1 PQLQR2M6N8KT COIL
(CONNECTORS)
J5 PSJS22A62Z LCD CONNECTOR
J6 PQJJ1C002Z HEADSET JACK
(OTHERS)
A1a PQJT10152Y CHARGE PAD
A1b PQJT10152Y CHARGE PAD
J1 PQJT10152Y CHARGE PAD
J2 PQJT10152Y CHARGE PAD
E101 PQJM146Z MICROPHONE
RFCAN 1 PQMC10417Z RFCAN 1
RFCAN 2 PQMC10418Z RFCAN 2
X1 PQVCF1036N3Z CRYSTAL OSCILLATOR
(RESISTORS)
R1 ERJ3GEYJ222 2.2k
R2 ERJ3GEYJ184 180k
R3 ERJ3GEYJ000 0
R4 ERJ3GEYJ330 33
R5 ERJ3GEYJ330 33
R6 ERJ3GEYJ471 470
R7 ERJ3GEYJ120 12
R8 ERJ3GEYJ471 470
R9 ERJ3GEYJ223 22k
R10 ERJ3GEYJ393 39k
R11 ERJ3GEYJ181 180
R12 ERJ3GEYJ181 180
R13 ERJ3GEYJ100 10
R14 ERJ3GEYJ124 120k
R15 ERJ3GEYJ473 47k
R16 PQ4R18XJR10 0.1
R17 ERJ3GEYJ683 68k
R18 ERJ3GEYJ563 56k
R20 ERJ3GEYJ181 180
R21 ERJ3GEYJ471 470
R22 ERJ3GEYJ120 12
R23 ERJ3GEYJ120 12
R24 ERJ3GEYJ471 470
R27 ERJ3GEYJ220 22
R28 ERJ3GEYJ220 22
R29 ERJ3GEYJ103 10k
R35 ERJ3GEYJ824 820k
R36 ERJ3EKF4303 430k
R37 ERJ3GEYJ224 220k
R42 ERJ3GEYJ153 15k
R43 ERJ3GEYJ560 56
R50 ERJ3GEYJ103 10k
R51 PQ4R18XJ471 470
R52 PQ4R10XJ122 1.2k
R54 ERJ3GEYJ224 220k
R55 ERJ3GEYJ104 100k
R56 PQ4R10XJ2R7 2.7
R59 ERJ3GEYJ103 10k
R60 ERJ3GEYJ103 10k
R61 ERJ3GEYJ224 220k
R62 ERJ3GEYJ104 100k
R67 ERJ3GEYJ101 100
R68 ERJ3GEYJ101 100
R69 ERJ3GEYJ104 100k
R70 ERJ3GEYJ104 100k
R404 ERJ3GEYJ1R0 1
R406 ERJ3GEYJ100 10
R408 ERJ3GEYJ561 560
R409 ERJ3GEYJ331 330
R410 ERJ3GEYJ273 27k
R411 ERJ3GEYJ472 4.7k
R412 ERJ3GEYJ272 2.7k
R413 ERJ3GEYJ682 6.8k
R414 ERJ3GEYJ183 18k
R415 ERJ3GEYJ152 1.5k
R416 ERJ3GEYJ331 330
R417 ERJ3GEYJ272 2.7k
Ref.
No.
Part No. Part Name & Description Remarks
R418 ERJ3GEYJ1R0 1
C47 ERJ3GEYJ473 47k
(CAPACITORS)
C1 ECUV1C683KBV 0.068
C2 ECUV1C683KBV 0.068
C3 ECUV1C683KBV 0.068
C4 ECST1AD227 220
C5 ECUV1C683KBV 0.068
C6 ECUV1H030CCV 3P
C7 ECUV1H220JCV 22P
C8 PQCUV1A105KB 1
C10 ECUV1H220JCV 22P
C12 ECUV1C104KBV 0.1
C13 ECUV1C104KBV 0.1
C14 ECUV1C104KBV 0.1
C15 ECUV1C104KBV 0.1
C16 ECUV1C683KBV 0.068
C17 ECUV1H100DCV 10P
C18 ECST1AY475 4.7
C19 ECUV1H100DCV 10P
C20 ECUV1H100DCV 10P
C21 ECUV1H100DCV 10P
C22 ECUV1H100DCV 10P
C23 ECUV1H100DCV 10P
C24 ECUV1H331JCV 330P
C25 ECUV1H100DCV 10P
C26 ECUV1H100DCV 10P
C27 ECUV1H100DCV 10P
C28 ECUV1A225KB 2.2
C29 ECUV1H100DCV 10P
C30 ECUV1C104KBV 0.1
C31 ECUV1C104KBV 0.1
C32 ECUV1C104KBV 0.1
C33 ECUV1C104KBV 0.1
C34 ECUV1H100DCV 10P
C35 ECST1AY106 10
C36 ECUV1C104KBV 0.1
C37 ECUV1C104KBV 0.1
C38 ECUV1H100DCV 10P
C39 PQCUV1C474KB 0.47
C40 PQCUV1C474KB 0.47
C41 ECUV1H100DCV 10P
C42 ECUV1C104KBV 0.1
C43 ECUV1C104KBV 0.1
C44 ECUV1C104KBV 0.1
C45 ECUV1C104KBV 0.1
C46 ECUV1C104KBV 0.1
C48 ECUV1C104KBV 0.1
C49 ECST1AY106 10
C50 ECUV1C104KBV 0.1
C51 ECUV1C104KBV 0.1
C52 PQCUV1E104MD 0.1 S
C53 ECUV1C104KBV 0.1
C54 ECUV1C104KBV 0.1
C55 ECUV1H103KBV 0.01
C56 ECUV1C683KBV 0.068
C57 ECUV1C104KBV 0.1
C58 ECUV1C104KBV 0.1
C59 ECUV1C104KBV 0.1
C60 ECUV1H100DCV 10P
C61 ECUV1H100DCV 10P
C62 ECUV1H100DCV 10P
C63 ECUV1C224ZFV 0.22
C64 ECUV1C224ZFV 0.22
C65 ECUV1H100DCV 10P
C66 ECUV1H100DCV 10P
C67 ECUV1H100DCV 10P
C400 ECUV1H1R8CCV 1.8
C402 ECUV1H100DCV 10P
C404 ECUV1H100DCV 10P
C405 ECUV1H100DCV 10P
C406 ECUV1H331JCV 330P
C407 ECUV1H100DCV 10P
