Panasonic KX-TCD705RUM - Handset

Ref.
No.
Part No. Part Name & Description Remarks
C424 ECUV1H1R8CCV 1.8
C425 ECUV1H1R8CCV 1.8
C426 ECUV1C104KBV 0.1
C427 ECUV1H100DCV 10P
C428 ECUV1H100DCV 10P
C429 ECUV1H100DCV 10P
C430 ECUV1C104KBV 0.1
C431 ECUV1H100DCV 10P
C432 ECUV1H4R7CCV 4.7
C433 ECUV1H100DCV 10P
C434 ECUV1H100DCV 10P
C435 ECUV1H2R2CCV 2.2
C436 ECUV1H100DCV 10P
C437 ECUV1H221JCV 220P
C438 ECUV1H1R5CCV 1.5
C439 ECUV1H010CCV 1P
C440 ECUV1H8R2CCV 8.2
C441 ECUV1H220JCV 22P
C442 ECUV1H1R8CCV 1.8
C443 ECUV1H1R8CCV 1.8
C444 ECUV1H1R8CCV 1.8
C445 ECUV1H100DCV 10P
C446 ECUV1C104KBV 0.1
C447 ECUV1H2R2CCV 2.2
C448 ECUV1H100DCV 10P
C449 ECUV1H100DCV 10P
C450 ECUV1H100DCV 10P
C451 ECUV1H100DCV 10P
C452 ECUV1H100DCV 10P
C453 ECUV1H2R7CCV 2.7
C454 ECUV1H2R2CCV 2.2
C455 ECUV1H100DCV 10P
C456 ECUV1H2R2CCV 2.2
C458 ECUV1H2R2CCV 2.2
13.2. Handset
13.2.1. CABINET AND ELECTRICAL
PARTS
Ref.
No.
Part No. Part Name & Description Remarks
101 L0AD02A00006 RECEIVER
102 PQKK10109Z1 BATTERY COVER (for KX-
TCD705RUS)
S
102 PQKK10109Z5 BATTERY COVER (for KX-
TCD705RUM)
S
103 L5CBDC00003 LCD DOT MATRIX
104 PQBC10323Y1 NAVIGATOR KEY S
105 PQBX10345Y1 FUNCTION BUTTON S
106 PQGG10116Z1 FRONT CABIET GRILL (for KX-
TCD705RUS)
S
106 PQGG10116Z5 FRONT CABIET GRILL (for KX-
TCD705RUM)
S
107 PQGP10176Y1 LCD PANEL (for KX-TCD705RUS) S
107 PQGP10176Y2 LCD PANEL (for KX-TCD705RUM) S
108 PQGT14534Z NAME LABEL (for KX-TCD705RUS)
108 PQGT14535Z NAME LABEL (for KX-TCD705RUM)
109 PQHS10457Z SPEAKER NET
110 PQHG10634X RUBBER
111 PQHR10779Y LCD HOLDER
112 PQHS10430Y LCD SPONGE
113 PQHS10467Z RECEIVER NET
114 PQHX10990Y SHEET PET
115 PQHX11030Z INSULATION TAPE
116 PQJC10046Z BATTERY TERMINALS (A)
117 PQJC10047Y BATTERY TERMINALS (B)
118 PQJC10048Y BATTERY TERMINALS (C)
119 PQJT10168Y CHARGE TERMINAL (L)
120 PQJT10169Y CHARGE TERMINAL (R)
121 PQKF10497Z1 REAR CABIET (for KX-
TCD705RUS)
S
Ref.
No.
Part No. Part Name & Description Remarks
121 PQKF10497Z5 REAR CABIET (for KX-
TCD705RUM)
S
122 PQKM10464Z1 FRONT CABINET (for KX-
TCD705RUS)
S
122 PQKM10464Z4 FRONT CABINET (for KX-
TCD705RUM)
S
123 PQSA10117Y ANTENNA
124 PQSX10155X RUBBER KEYPAD (for KX-
TCD705RUS)
124 PQSX10155Y RUBBER KEYPAD (for KX-
TCD705RUM)
125 PQHG10589Y SPEAKER SPONGE
126 PQHS10429X DOUBLE SIDED TAPE
127 PQAS3P07Y SPEAKER
128 PQHR10778Z SPEAKER HOLDER
129 PQBC10314Z1 SP BUTTON S
130 PQHR10781Z LCD PLATE
131 PQHX10962Z LCD COVER SHEET
132 PQHX10963Y LCD REFLECTOR SHEET
133 PQKE10108Z1 EAR PIECE CAP (for KX-
TCD705RUS)
S
133 PQKE10108Z2 EAR PIECE CAP (for KX-
TCD705RUM)
S
13.2.2. MAIN P.C.BOARD PARTS
Ref.
No.
Part No. Part Name & Description Remarks
PCB100 PQWPCD735CER MAIN P.C.BOARD ASS´Y (RTL)
(ICS)
IC1 PQVI6723L22 IC
IC2 C3EBHC000001 IC S
IC3 PQWICD735CER IC
IC400 PMB6818 IC
IC402 PMB6610V12 IC S
HF_AM1 PQVINJM2135M IC
(TRANSISTORS)
T1 B1GBCFGC0001 TRANSISTOR(SI) S
T3 PQVTSI2302DS TRANSISTOR(SI)
T5 B1GBCFGC0001 TRANSISTOR(SI) S
T6 PQVTBC80725T TRANSISTOR(SI) S
T7 PQVTBC80740T TRANSISTOR(SI) S
T8 B1GBCFGC0001 TRANSISTOR(SI) S
T11 DTC143XKA106 TRANSISTOR(SI)
T12 DTC143XKA106 TRANSISTOR(SI)
T400 BC858BW TRANSISTOR(SI)
(DIODES)
D1 LNJ115W89RA DIODE(SI)
D2 LNJ115W89RA DIODE(SI)
D3 LNJ115W89RA DIODE(SI)
D4 MA111 DIODE(SI)
D5 MA111 DIODE(SI)
D6 MA111 DIODE(SI)
D7 MA8047 DIODE(SI)
D8 MA112 DIODE(SI)
D9 MA8047 DIODE(SI)
D11 B3ABB0000001 DIODE(SI) S
D12 B3ABB0000001 DIODE(SI) S
D13 B3ABB0000001 DIODE(SI) S
D14 B3ABB0000001 DIODE(SI) S
D16 MA2H73600L DIODE(SI)
D17 PQVDBR1111C DIODE(SI) S
D18 PQVDBZV55C47 DIODE(SI) S
D19 PQVDBZV55C47 DIODE(SI) S
D21 PQVDBZV55C47 DIODE(SI) S
D400 PQVDBAR6405 DIODE(SI)
(COILS)
L1 G1A220F00005 COIL
L2 ELJPA100KF COIL
L3 ELJPA100KF COIL
L4 PQLQR2K1A102 COIL
L400 G1C4N7Z00005 COIL
L401 G1C4N7Z00005 COIL
L402 G1C22NKA0025 COIL
49
KX-TCD705RUM / KX-TCD705RUS
