14.3.2. MeterPulse Billing
Address Default Name Type Description
0140-0141 00 01
MSB LSB
MpBill.Unit D Meter-pulse billing unit
0142-0145 00..00 MpBill.PstnLineTotal D Meter-pulse billing total for PSTN line.
MSB in 0160h.
0146-0149 00..00 MpBill.Hs1 D Meter-pulse billing total for HS1
014A-014D 00..00 MpBill.Hs2 D Meter-pulse billing total for HS2
014E-0152 00..00 MpBill.Hs3 D Meter-pulse billing total for HS3
0153-0156 00..00 MpBill.Hs4 D Meter-pulse billing total for HS4
0157-0159 00..00 MpBill.Hs5 D Meter-pulse billing total for HS5
015A-015D 00..00 MpBill.Hs6 D Meter-pulse billing total for HS6
14.3.3. Free Block 1
Address Default Name Type Description
161-162 00..00 RunTimeErrorLogAddress - Last RunTime error (uint16)
14.3.4. Audio Setup
Address Default Name Type Description
0200 0x14 SpeakerGain D Gain for speaker output (GX2), see Gain index values
0201 0x11 MicGain D Gain for microphone input (GR1), see Gain index values
0202 - 0203
MSB - LSB
0x3BCA GX1Gain D Gain for GX1 gaincell, see appendix Gain for transmit and
receive
0204 - 0205
MSB - LSB
0x0110 GR2Gain D Gain for GR2 gaincell, see appendix Gain for transmit and
receive.
0206 0x40 ClipperConfig (Lim_Sc) D Soft clipping configuration, see DSP1.7.2.2
0207 0x79 Gain after soft clipping
(GX1SC)
D Soft clipping configuration, see appendix
Amplification by Shift&Add coeffecients
0208 0xD5 OnhookMicGain D On-hook gain-settings for analogue-in.
Bit 0..5 : GR1, see Gain index values.
Bit 6..7 : AIG, 11=6dB
11=6dB, 01=12dB, 10=18dB
0209 - 020B
MSB - LSB
- Reserved -
020C 0xBB GD1Gain D Gain for GD1 gaincell (high DTMF tone), see appendix
Gain for tonegenerator
020D 0x24 GD2Gain D Gain for GD2 gaincell (low DTMF tone), see appendix Gain
for tonegenerator
020E 0x40 GDRGain D Gain for GDR gaincell (DTMF tone to handset), see
appendix Amplification by Shift&Add coeffecients
020F 0x30 GDXGain D Gain for GDX gaincell (DTMF tone to line), see appendix
Amplification by Shift&Add coeffecients
0210 2 RingerVolumeStep D Current ringer volume selected by the user
0211 0x00 RingerVolumeData0 D Volume data for ringer volume step 0. Range 0-100.
0212 0x0C RingerVolumeData1 D Volume data for ringer volume step 1. Range 0-100.
0213 0x18 RingerVolumeData2 D Volume data for ringer volume step 2. Range 0-100.
0214 0x30 RingerVolumeData3 D Volume data for ringer volume step 3. Range 0-100.
0215 10 ToneVolumeData D Volume data for tone volume. Range 0-100.
0216 - 021F - - Reserved for audio parameters
0220 - 0228 - - Reserved for audio parameters
0229 0x21 GCR D GCR register
022A 0x20 ACR D ACR register
022B - 023E 0x00 D Unused
022F 0x21 SoftLimiter1 D LIM_HIGHR
0230 0x18 SoftLimiter1 D LIM_LOWR
0231 0x40 SoftLimiter2 D LPOR + TIM_OVR
0232 0x21 SoftLimiter2 D GOR
0233 - 023F - - Reserved for audio parameters
53
