Panasonic KX-TCD705RUM - 2 Disassembly Instrucutions

2 DISASSEMBLY INSTRUCUTIONS
Shown in Fig.- To Remove Remove
1 Lower Cabinet Screws (2.6 × 10).................(A) × 2
2 Main P.C.B of base Screw (2.6 × 10).................(B) × 1
3 Main P.C.B of base Charge wire solder
4 Rear Cabinet of handset Screws (2 × 8)......................(C) × 2
5 Main P.C.B of handset Screws (2 × 6)......................(D) × 2
6
KX-TCD705RUM / KX-TCD705RUS
