Address Default Name Type Description
1F01 C6 UIConfig00 D bit 0 - Direct call 1 = on /0 = off
bit 1 - StandbyDisplay00 00 = Off / 01 = Clock
bit 2 - StandbyDisplay01 10 = PpNo / 11 = FpNo
bit 3 - BatteryType 1 = Ni-Cd/0 = Ni-Mh
bit 4 - Call barring
bit 5 - Autio talk
bit 6 - TalkmodeDisplay00 11 = Talk time
bit 7 - TalkmodeDisplay01 01 = Talk cost
10 = Phone number
15.3.7. VolumeSettings
Address Default Name Type Description
1F12 10 BeepVolSetting D Soundlevel of buzzerbeeps, who is not affected by
the ringervolume.
Hightime = Cycle/VolumeLevel
1F13 0A VolumeLevel1 D Hightime = Cycle/VolumeLevel
1F14 08 VolumeLevel2 D Hightime = Cycle/VolumeLevel
1F15 07 VolumeLevel3 D Hightime = Cycle/VolumeLevel
1F16 06 VolumeLevel4 D Hightime = Cycle/VolumeLevel
1F17 05 VolumeLevel5 D Hightime = Cycle/VolumeLevel
1F18 03 VolumeLevel6 D Hightime = Cycle/VolumeLevel
nb. There is no restriction in range. That is if a value is put in, who is too high, the hightime will become zero and
therefore onlly clickingsounds will be heard.
15.3.8. Audiogains
Address Default Name Type Description
1F23 16 GX-index D Gain-transmit (values ranging from 0x00 to 0x24,
each step representing 1 dB)
1F24 1B GR-index D Gain-receive (values ranging from 0x00 to 0x24,
each step representing 1 dB)
1F25 04 SideToneGain D SideToneGain (T67DSP-PPV2xD4-7600, table
1.10).
1F26 11 SpPhGX-index D Gain-transmit for speakerphone (values ranging
from 0x00 to 0x24, each step representing 1 dB)
1F27 98 SpPhGR-index D Bit7 - AOG when speakerphone (0 as default)
Bit6 - AOG2 when speakerphone (1 as default)
Bit5 - Extra 6dB attenuation using the method
described on page 120 in ""T672X-XV01D7-7600".
0 = 0dB, 1 = -6dB, when speakerphone (1 as
default)
Gain-receivet for speakerphone (values ranging
from 0x00 to 0x1F, each step representing 1 dB)
1F28 08 SpPhSideToneGain D SideToneGaint for speakerphone
(T67DSP-PPV2xD4-7600, table 1.10).
1F29 01 SpPhEnableState D Indicates in what state the chip-enable on HF-AM1
has to be to enable the speakerphone-amplifier
0x01 - P0.7(SP_AMP) set to high enables HF_AM1
0x00 - P0.7(SP_AMP) set to low enables HF_AM1
1F2A 16 HeadsetGX-index D Gain-transmit when headset mounted (values
ranging from 0x00 to 0x24, each step representing 1
dB)
1F2B 1B HeadsetGR-index D Gain-receive when headset mounted (values
ranging from 0x00 to 0x24, each step representing 1
dB)
1F2C 04 HeadsetSideToneGain D SideToneGaint when headset mounted
(T67DSP-PPV2xD4-7600, table 1.10).
1F2D 20 HeadsetDetectVoltage D Determines at which voltage below which the
headset will be detected.
HeadsetDetectVoltage[eeprom] = [ADC-steps] =
LowVoltage[mV] / (3.2 * 9.53[mV/step])
15.3.9. Call cost-configuration
Address Default Name Type Description
1F36 02 MenusEnabled D Used to disable/enable functionality.
bit 0: Callcost - 0 disabled/1 enableed.
bit1: Batteryselection - 0 disabled/1 enabled.
