Panasonic KX-TDA15

2.7 Connection of DECT Portable Stations
Installation Manual 105
Setting and Installing the CS Temporarily for Site Survey
1. Switch the Radio Signal Test switch from OFF to ON.
2. Set the channel number switches as desired.
Note
If more than 1 CS is in Radio Signal Test mode, each CS must have a unique channel number.
Channel Number Switch
Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 Channel 9
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
1
2
3
4
DIP Switch
1
2
3
4
5
6
OFF ON
Radio Signal
Test Switch
Channel 0
1
2
3
4
Keep this switch at the default
"OFF" position. Otherwise, the
CS will not function.
