Panasonic KX-TDA15

2.2 Installation of the Hybrid IP-PBX
Installation Manual 39
2.2.6 Installing/Removing the Optional Service Cards
Slot Position
Slot Restrictions
The following table shows the slot restrictions. " " indicates that the slot supports the optional service card.
*
1
Slots 10 and 11 accept only cards that do not have external ports. Therefore, these slots do not have
removable cover plates.
*
2
Slot 08 contains the pre-installed EXT-CID card.
*
3
Slot 02 contains the pre-installed BRI2 card.
*
4
Slot 01 contains the pre-installed Super Hybrid Ports. No optional service card can be installed.
Card Slot Number
Type Max 0304050607091011
LCOT2 1
BRI2 1
BRI1 1
SIP-GW4 1
2IP-GW4 1
IP-EXT4 1
DLC8
1
*1
SLC8
DPH4
1
*2
DPH2
ECHO8 1
MSG2 2
SVM2 2
02*
3
03
04
05
06
07
08*
2
09
10*
1
11*
1
01*
4
