Panasonic KX-TDA15

2 Installation Manual
System Components
Compatible Panasonic Proprietary Telephones
The Hybrid IP-PBX supports the following telephones:
• Digital proprietary telephones (e.g., KX-T7600 series)
• Analogue proprietary telephones (e.g., KX-T7700 series)
• IP proprietary telephones (e.g., KX-NT136)
• Portable stations (e.g., KX-TCA155, KX-TCA255)
• DSS consoles (e.g., KX-T7640)
• Single line telephones (e.g., KX-T7710)
System Components Table
Category Model No. Description
Main Unit KX-TDA15 Main Unit
Trunk Cards KX-TDA3183 2-Port Analogue Trunk Card (LCOT2)
KX-TDA3280 2-Port BRI Card (BRI2)
KX-TDA3283 1-Port BRI Card (BRI1)
KX-TDA3450 4-Channel SIP Trunk Card (SIP-GW4)
KX-TDA3451 4-Channel VoIP DSP Card (SIP-DSP4)
KX-TDA3480 4-Channel VoIP Gateway Card (IP-GW4)
Extension Cards KX-TDA3172 8-Port Digital Extension Card (DLC8)
KX-TDA3174 8-Port Single Line Telephone Extension Card (SLC8)
KX-TDA3470 4-Channel VoIP Extension Card (IP-EXT4)
Other Cards KX-TDA3161 4-Port Doorphone Card (DPH4)
KX-TDA3162 2-Port Doorphone Card (German Type) (DPH2)
KX-TDA3166 8-Channel Echo Canceller Card (ECHO8)
KX-TDA3191 2-Channel Message Card (MSG2)
KX-TDA3192 2-Channel Simplified Voice Message Card (SVM2)
– Extension Caller ID Card (EXT-CID)
Optional SD Memory
Cards
KX-TDA3820 SD Memory Card for Software Upgrade
KX-TDA3920 SD Memory Card for Software Upgrade to Enhanced Version
Cell Stations (CSs) KX-TDA0141CE 2-Channel Cell Station Unit Using a Super Hybrid Port or a DLC
Card for DECT Portable Station
Proprietary Equipment KX-T30865 Doorphone
