Panasonic KX-TDA15

2.7 Connection of DECT Portable Stations
Installation Manual 113
Connecting the CS
1. Connect the cable from a Super Hybrid Port or the DLC8 card to the CS.
2. Pass the cable through the groove of the CS (in any direction depending on your preference).
Modular
To a Super Hybrid Port
or DLC8 card
To a Super Hybrid Port
or DLC8 card
TO MAIN UNIT
/ PABX
