2.8 Connection of Doorphones, Door Openers, External Sensors, and External Relays
Installation Manual 125
5. Connect the terminal box to the DPH4 card in the Hybrid IP-PBX using the telephone line cords
included with the card.
Telephone Line Cord
To DPH4 card
To doorphones
