Panasonic KX-TDA15

4.1 Troubleshooting
154 Installation Manual
5 Sub Code The 5-digit sub code of the relevant hardware (1XXYY).
• 1: Cabinet number
• XX: Slot number
00 to 11
(00: MPR card slot; 01: Super hybrid ports; 02 to 11:
Slots for optional service cards)
• YY: Physical port number
– For optional service cards:
Physical port number (01 to 16) will be displayed.
– For optional service cards that are installed in
Slots 08 to 11:
Sub slot number 1 + port number (1 to 4) will be
displayed as follows:
• Sub slot 1: 11 to 14
Note
When there are no parameters for the slot and physical port
numbers, XX and YY will be displayed as "00".
Example: Sub code for MPR card = 10000
6 Error Message A description of the error.
7 Log Information Displays probable causes of the errors and their solutions.
Item Description
