2.2 Installation of the Hybrid IP-PBX
54 Installation Manual
Mounting on Concrete or Mortar Wall
CAUTION
Drive mounting screws into the wall. Be careful to avoid touching any metal laths, wire laths or metal
plates in the wall.
1. Place the reference for wall mounting (on the following page) on the wall to mark the 2 screw positions.
2. Install two anchor plugs (user-supplied) in the wall.
3. Install the screws (included) in the wall.
4. Hook the AC adaptor on the screw heads.
Note
Be careful not to drop the AC adaptor.
110 mm
Hammer
Anchor Plug
8 mm
30 mm
Drive the screw
to this position.
To Next Page
