Panasonic Lumix DC-GX9 User Manual

52
Basics
Buttons/Dials Used for Recording
■
Using the level gauge
The yellow line indicates the current angle. Correct the angle of the camera so that it
matches the white line.
Tilting up or down
• In this case, it is facing upward.
Tilting left or right
• In this case, the right side has
dropped.
• When the camera is tilted very little or not at all, the level gauge will turn green.
●
Even when angle is corrected, there may be an error of about ±1 degree.
●
The level gauge may not be displayed correctly or the direction detect function may not operate
correctly if the pictures are taken with the camera pointing sharply up or down.
During playback
With information
Detailed information
display
*
1
Without information
([Highlight])
*
2
Without information
100-0001
1/5
10:00 1.DEC.2018
*
1
Press to switch between the following display modes:
– Detailed information display
– Histogram display
– Photo style, Highlight shadow display
– White balance display
– Lens information display
*
2
This screen is displayed only when [Highlight] in the [Custom] ([Monitor / Display]) menu is set to
[ON].

Panasonic Lumix DC-GX9 Specifications

General

Camera Type	Mirrorless
Sensor Type	Live MOS
Effective Pixels	20.3 MP
Image Processor	Venus Engine
Continuous Shooting	9 fps
LCD Screen Size	3.0 inches
Screen Type	Tilting Touchscreen
Built-in Flash	Yes
Wireless Connectivity	Wi-Fi, Bluetooth
Dimensions	124 x 72.1 x 46.8 mm
Lens Mount	Micro Four Thirds
Sensor Size	17.3 x 13.0 mm
ISO Range	200-25600 (extendable to 100)
Shutter Speed	60 sec
Autofocus System	Contrast Detection
Image Stabilization	5-axis
Viewfinder Type	Electronic
Viewfinder Resolution	2, 760, 000 dots
LCD Screen Resolution	1, 240, 000 dots
Video Recording	4K UHD at 30p
Battery	DMW-BLG10
Battery Life	260 shots (CIPA standard)
Weight	407 g (with battery and SD card)
