100
Recording
When you want to take a sharp picture of a fast moving subject, set with a faster shutter
speed. When you want to create a trail effect, set to a slower shutter speed.
1
Set the mode dial to [ ].
2
Rotate the rear dial to set the shutter speed.
A Shutter speed
B Exposure meter
It will switch between shutter speed setting operation and Exposure Compensation
operation every time the rear dial is pressed.
The effects of the set shutter speed will not be visible on the recording screen. To check
on the recording screen, please use [Preview]. (P104)
The brightness of the screen and the recorded pictures may differ. Check the pictures on the
playback screen.
Rotate the rear dial to display the [Expo.Meter]. Unsuitable areas of the range are displayed in
red.
If the exposure is not adequate, the aperture value and the shutter speed turn red and blink
when the shutter button is pressed halfway.
We recommend using a tripod when the shutter speed is slow.
The [Sensitivity] is automatically set to [AUTO] when you switch the Recording Mode to
Shutter-Priority AE Mode while the [Sensitivity] is set to [ ] (Intelligent).
Not available in these cases:
When the flash is activated, the fastest shutter speed that can be selected is 1/160th of a
second. (P142)
The shutter speed slower than 1 second is not available when [Electronic Shutter] is set to
[ON].
Shutter-Priority AE Mode
Shutter speed:
Slow
Shutter speed:
Fast
It becomes easier to
express movement.
It becomes easier to
freeze movement.
SS
SS
SS
F
250
250
250
60
11 8.0 5.6 4.0
250 500125
1
000
A
B
DMC-G6PDF-VQT4Z78_eng.book 100 ページ 2013年4月25日 木曜日 午前10時5分

Table of Contents

Other manuals for Panasonic Lumix DMC-G6

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-G6 and is the answer not in the manual?

Panasonic Lumix DMC-G6 Specifications

General IconGeneral
Megapixel18.05 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels18.31 MP
Image sensor size- \
Image formats supportedJPG
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Image sensor size (W x H)17.3 x 13 mm
Still image resolution(s)1712 x 1712, 1824 x 1024, 1824 x 1216, 1824 x 1368, 1920 x 1080, 2448 x 2448, 3264 x 1840, 3264 x 2448, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom4 x
Optical zoom- x
Focal length range14 - 32 mm
Maximum aperture number5.6
Minimum aperture number3.5
Lens structure (elements/groups)12/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Auto focusing (AF) modesContinuous Auto Focus, Contrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Spot
ISO sensitivity160, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)160
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed0.00625 s
Power source typeBattery
Video formats supportedMP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Audio formats supportedAAC
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Display resolution (numeric)1036 pixels
Magnification1.4 x
USB version2.0
Product colorBlack
Scene modesBacklight
Image editingCrop, Resizing
Photo effects-
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesAuto, Manual, Movie, Scene
Camera playbackMovie, Single image
Self-timer delay2, 10 s
Sharpness levelsSoft, Vivid
Camera file systemDCF, Exif 2.3, RAW
Image quality adjustmentBrightness, Contrast, Saturation
On Screen Display (OSD) languagesCZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Battery voltage7.2 V
Battery capacity1200 mAh
Battery life (CIPA standard)330 shots
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Cables includedUSB
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Weight and Dimensions IconWeight and Dimensions
Depth71.4 mm
Width122.45 mm
Height84.6 mm
Weight340 g
Weight (including battery)555 g
