199
Recording
7 Touch [OK].
Confirmation screen is displayed. It is executed when [Yes]
is selected.
Motion pictures can also be created from [Stop Motion
Video] in the [Playback] menu. (P235)
Adding pictures to the Stop Motion Animation group
Selecting [Additional] in step
2 will display group pictures recorded with [Stop Motion
Animation]. Select a set of group pictures, touch [Set], and then select [Yes] on the
confirmation screen.
Automatic recording may not take place at set intervals because recording takes time under
certain recording conditions, such as when the flash is used for recording.
When a picture quality different from the aspect ratio of the original pictures is selected, black
strips will be displayed on the top and bottom or the left and right of the motion picture.
When a picture quality with a picture size larger than the original pictures is selected, the
resolution of the motion picture will deteriorate.
We recommend that you use a sufficiently charged battery or an AC adaptor (optional) and a
DC coupler (optional).
If power supply is lost by unplugging the AC adaptor or due to a blackout while creating a
motion picture with the AC adaptor, the motion picture you are creating will not be recorded.
A motion picture that exceeds the recording time of 29 minutes and 59 seconds and a motion
picture that exceeds the file size of 4 GB cannot be created.
A motion picture shorter than 1 second is displayed as “0s” on the motion picture recording time
(P80).
If only one picture was taken, the picture is not saved as a group picture. A picture cannot be
selected from [Additional] when it is the only one that was taken.
Not available in these cases:
[Stop Motion Animation] is not available in the following cases.
[Multi Exp.]
When using [Time Lapse Shot]
Refer to P106 for details.
[Panorama Settings]
DMC-G6PDF-VQT4Z78_eng.book 199 ページ 2013年4月25日 木曜日 午前10時5分

Table of Contents

Other manuals for Panasonic Lumix DMC-G6

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-G6 and is the answer not in the manual?

Panasonic Lumix DMC-G6 Specifications

General IconGeneral
Megapixel18.05 MP
Camera typeMILC
Sensor typeLive MOS
Image stabilizerYes
Total megapixels18.31 MP
Image sensor size- \
Image formats supportedJPG
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Image sensor size (W x H)17.3 x 13 mm
Still image resolution(s)1712 x 1712, 1824 x 1024, 1824 x 1216, 1824 x 1368, 1920 x 1080, 2448 x 2448, 3264 x 1840, 3264 x 2448, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom4 x
Optical zoom- x
Focal length range14 - 32 mm
Maximum aperture number5.6
Minimum aperture number3.5
Lens structure (elements/groups)12/9
Maximum focal length (35mm film equiv)84 mm
Minimum focal length (35mm film equiv)28 mm
Auto focusing (AF) modesContinuous Auto Focus, Contrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Spot
ISO sensitivity160, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)160
Light exposure controlProgram AE
Light exposure correction± 5EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed60 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed0.00625 s
Power source typeBattery
Video formats supportedMP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Audio formats supportedAAC
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display aspect ratio3:2
Display resolution (numeric)1036 pixels
Magnification1.4 x
USB version2.0
Product colorBlack
Scene modesBacklight
Image editingCrop, Resizing
Photo effects-
White balanceAuto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modesAuto, Manual, Movie, Scene
Camera playbackMovie, Single image
Self-timer delay2, 10 s
Sharpness levelsSoft, Vivid
Camera file systemDCF, Exif 2.3, RAW
Image quality adjustmentBrightness, Contrast, Saturation
On Screen Display (OSD) languagesCZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Battery voltage7.2 V
Battery capacity1200 mAh
Battery life (CIPA standard)330 shots
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)10 - 80 %
Cables includedUSB
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Weight and Dimensions IconWeight and Dimensions
Depth71.4 mm
Width122.45 mm
Height84.6 mm
Weight340 g
Weight (including battery)555 g
