35
Preparation
Inserting and Removing the Card (optional)/
the Battery
• Check that this unit is turned off.
• We recommend using a Panasonic card.
1
Slide the release lever in the
direction of the arrow and open
the card/battery door.
• Always use genuine Panasonic
batteries.
• If you use other batteries, we cannot
guarantee the quality of this product.
2
Battery: Being careful about the
battery orientation, insert all the
way until you hear a locking
sound and then check that it is
locked by lever A.
Pull the lever A in the direction of
the arrow to remove the battery.
Card: Push it securely all the way
until you hear a “click” while
being careful about the direction in which you insert it.
To remove the card, push the card until it clicks, then pull the card
out upright.
B: Do not touch the connection terminals of the card.
3
1: Close the card/battery door.
2: Slide the release lever in the
direction of the arrow.
