Panasonic Lumix DMC-G6 User Manual

47
Preparation
You can set the background for the menu screen according to your preferences. You can
also set one of the recorded still images as the background on the top menu screen.
1 Press [MENU/SET] to display the top menu.
2 Touch [Background Image].
3 Touch the item.
• Touch [Registered image] or [No static image] to change to the selected background.
4 (When [From SD card] is selected) Drag the screen
horizontally and select an image.
5 (When [From SD card] is selected) Touch [Set].
•
Confirmation screen is displayed. It is executed when [Yes]
is selected.
Not available in these cases:
•
Images recorded using another device cannot be used as the background.
1 Select [Menu Background] on the [Setup] menu. (P43)
2 Select and touch background color.
•
You can select the background color from four colors.
• Exit the menu after it is set.
Setting the menu screen background
Setting the top menu screen background
[From SD card]
Select a background from the recorded images. The selected
image is registered in this unit. (Only 1 image can be registered. If
an image has already been registered, it will be overwritten.)
[Registered image] Set the last image selected from the SD card as the background.
[No static image] Set a background without an image.
Setting the menu screen background
6HW
DMC-G6PDF-VQT4Z78_eng.book 47 ページ ２０１３年４月２５日 木曜日 午前１０時５分

Panasonic Lumix DMC-G6 Specifications

General

Megapixel	18.05 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	18.31 MP
Image sensor size	- \
Image formats supported	JPG
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	1712 x 1712, 1824 x 1024, 1824 x 1216, 1824 x 1368, 1920 x 1080, 2448 x 2448, 3264 x 1840, 3264 x 2448, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 32 mm
Maximum aperture number	5.6
Minimum aperture number	3.5
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	160, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	160
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	0.00625 s
Power source type	Battery
Video formats supported	MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	AAC
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1036 pixels
Magnification	1.4 x
USB version	2.0
Product color	Black
Scene modes	Backlight
Image editing	Crop, Resizing
Photo effects	-
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Auto, Manual, Movie, Scene
Camera playback	Movie, Single image
Self-timer delay	2, 10 s
Sharpness levels	Soft, Vivid
Camera file system	DCF, Exif 2.3, RAW
Image quality adjustment	Brightness, Contrast, Saturation
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	330 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)

Weight and Dimensions

Depth	71.4 mm
Width	122.45 mm
Height	84.6 mm
Weight	340 g
Weight (including battery)	555 g
