Panasonic Lumix DMC-G6 User Manual

170
Recording
Turning on/not turning on the AF Assist Lamp
AF assist lamp will illuminate the subject when the shutter button is pressed halfway,
making it easier for the camera to focus when recording in low light conditions. (Larger AF
area is displayed depending on the recording conditions.)
• The effective range of the AF Assist Lamp is different depending on the lens used.
– When the interchangeable lens (H-PS14042, H-FS14140, H-FS1442A, H-FS014042,
H-FS45150) is attached and at Wide: Approx. 1.0 m (3.3 feet) to 3.0 m (9.8 feet)
• The AF Assist Lamp is valid only for the subject in the center of the screen. Use it by
positioning the subject in the center of the screen.
• Remove the lens hood.
• When you do not want to use the AF Assist Lamp (e.g. when taking pictures of animals in dark
places), set the [AF Assist Lamp] to [OFF]. In this case, it will become more difficult to focus on
the subject.
• The AF Assist Lamp gets slightly blocked when the interchangeable lens (H-PS14042,
H-FS14140, H-FS1442A, H-FS014042, H-FS45150) is used, but it does not affect the
performance.
• The AF Assist Lamp may be greatly blocked, and it may become harder to focus when a lens
with large diameter is used.
• The setting for the [AF Assist Lamp] is fixed to [OFF] in the following cases.
– [Distinct Scenery]/[Bright Blue Sky]/[Romantic Sunset Glow]/[Vivid Sunset Glow]/[Glistening
Water]/[Clear Nightscape]/[Cool Night Sky]/[Warm Glowing Nightscape]/[Artistic Nightscape]
(Scene Guide Mode)
Recording/not recording even when focus is not achieved
[FOCUS]:
You cannot take a picture until the subject is brought into focus.
[RELEASE]:
This gives priority to the best time to take a picture so you can take a picture when the
shutter button is pressed fully.
•
When set to [RELEASE], please be aware that focus may not be achieved even with [Focus
Mode] set to [AFS], [AFF] or [AFC].
• [Focus/Release Priority] is disabled during motion picture recording.
Adjusting/not adjusting the focus manually after achieving Auto Focus
When AF Lock is ON (press the shutter button halfway with the [Focus Mode] set to [AFS]
or set AF Lock using [AF/AE Lock]), you can make fine adjustments to the focus manually.
[MENU] > [Custom]>[AF Assist Lamp]>[ON]/[OFF]
[MENU] > [Custom]>[Focus/Release Priority]
[MENU] > [Custom]>[AF+MF]>[ON]/[OFF]
DMC-G6PDF-VQT4Z78_eng.book 170 ページ ２０１３年４月２５日 木曜日 午前１０時５分

Panasonic Lumix DMC-G6 Specifications

General

Megapixel	18.05 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	18.31 MP
Image sensor size	- \
Image formats supported	JPG
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	1712 x 1712, 1824 x 1024, 1824 x 1216, 1824 x 1368, 1920 x 1080, 2448 x 2448, 3264 x 1840, 3264 x 2448, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 32 mm
Maximum aperture number	5.6
Minimum aperture number	3.5
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	160, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	160
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	0.00625 s
Power source type	Battery
Video formats supported	MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	AAC
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1036 pixels
Magnification	1.4 x
USB version	2.0
Product color	Black
Scene modes	Backlight
Image editing	Crop, Resizing
Photo effects	-
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Auto, Manual, Movie, Scene
Camera playback	Movie, Single image
Self-timer delay	2, 10 s
Sharpness levels	Soft, Vivid
Camera file system	DCF, Exif 2.3, RAW
Image quality adjustment	Brightness, Contrast, Saturation
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	330 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)

Weight and Dimensions

Depth	71.4 mm
Width	122.45 mm
Height	84.6 mm
Weight	340 g
Weight (including battery)	555 g
