Panasonic Lumix DMC-G6 User Manual

75
Basic
∫ About the tilt sensor display
With the tilt sensor displayed, it is easy to correct the tilt of the camera etc.
1 Press [DISP.] to display the tilt sensor.
2 Check the tilt of the camera.
A Horizontal direction:
Correcting tilt to the left
B Vertical direction:
Correcting downward tilt
•
When the tilt of the camera is little, the indicator changes to green.
• When recording with a vertical orientation, the display automatically switches to a
vertically orientated display.
• Even after correcting the tilt, there may still be an error of approximately ± 1°.
• When a function button is set to [Level Gauge], the tilt sensor display can be switched on/off by
pressing the function button.
Not available in these cases:
•
Tilt sensor display may not be displayed correctly when this unit is in motion.
• When tilted significantly upwards or downwards to record, the tilt sensor display may not be
displayed correctly, and the Direction Detection Function (P65) may not work correctly.

DMC-G6PDF-VQT4Z78_eng.book 75 ページ ２０１３年４月２５日 木曜日 午前１０時５分

Panasonic Lumix DMC-G6 Specifications

General

Megapixel	18.05 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	18.31 MP
Image sensor size	- \
Image formats supported	JPG
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Image sensor size (W x H)	17.3 x 13 mm
Still image resolution(s)	1712 x 1712, 1824 x 1024, 1824 x 1216, 1824 x 1368, 1920 x 1080, 2448 x 2448, 3264 x 1840, 3264 x 2448, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 32 mm
Maximum aperture number	5.6
Minimum aperture number	3.5
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Single Auto Focus, Tracking Auto Focus
Light metering	Centre-weighted, Spot
ISO sensitivity	160, 200, 400, 800, 1600, 3200, 6400, 12800, 25600
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	160
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	0.00625 s
Power source type	Battery
Video formats supported	MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio formats supported	AAC
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Display resolution (numeric)	1036 pixels
Magnification	1.4 x
USB version	2.0
Product color	Black
Scene modes	Backlight
Image editing	Crop, Resizing
Photo effects	-
White balance	Auto, Cloudy, Daylight, Flash, Incandescent, Shade
Shooting modes	Auto, Manual, Movie, Scene
Camera playback	Movie, Single image
Self-timer delay	2, 10 s
Sharpness levels	Soft, Vivid
Camera file system	DCF, Exif 2.3, RAW
Image quality adjustment	Brightness, Contrast, Saturation
On Screen Display (OSD) languages	CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, HUN, ITA, JPN, POL, POR, SWE, TUR
Battery voltage	7.2 V
Battery capacity	1200 mAh
Battery life (CIPA standard)	330 shots
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Cables included	USB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)

Weight and Dimensions

Depth	71.4 mm
Width	122.45 mm
Height	84.6 mm
Weight	340 g
Weight (including battery)	555 g
