Page #280 background imageLoading...
Page #280 background image
Others
Usage cautions and notes
VQT5A33
- 280 -
When not using for a while
Turn off the camera before removing battery and card (ensure that battery is removed to prevent
damage through over-discharge).
Do not leave in contact with rubber or plastic bags.
Store together with a drying agent (silica gel) if leaving in drawer, etc. Store batteries in cool (15 °C
to 25 °C (59 °F to 77 °F)) places with low humidity (40%RH to 60%RH) and no major temperature
changes.
Charge battery once per year and use completely before storing again.
Memory cards
To prevent damage to cards and data
Avoid high temperatures, direct sunlight, electromagnetic waves, and static electricity.
Do not bend, drop, or expose to strong impacts.
Do not touch terminals on reverse of card or allow them to become dirty or wet.
When disposing of/transferring memory cards
If using the “format” or “delete” functions on your camera or computer, this only changes the file
management information, and does not completely delete the data from within the memory card.
When disposing of or transferring your memory cards, we recommend physically destroying the
memory card itself, or using commercially available computer data erasing software to completely
delete the data from the card. Data within memory cards should be managed responsibly.
LCD Monitor/Viewfinder
Do not press hard on the LCD monitor. This may cause uneven display and damage the monitor.
In cold climates or other situations when the camera becomes cold, the LCD monitor or the
viewfinder may appear slightly darker than normal immediately after the camera is turned on.
Normal brightness will return once the internal components have warmed up.
The LCD monitor and viewfinder are made with extremely high precision technology. However
there may be some dark or bright spots (red, blue or green) on the screen. This is not a
malfunction. The LCD monitor and viewfinder screens are controlled with extremely high precision
(greater than 99.99%), but some pixels (under 0.01%) may be inactive. The spots will not be
recorded on pictures on the built-in memory or a card.

Table of Contents

Other manuals for Panasonic LUMIX DMC-LF1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-LF1 and is the answer not in the manual?

Panasonic LUMIX DMC-LF1 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeCompact camera
Sensor typeLive MOS
Image stabilizerYes
Image sensor size1/1.7 \
Image formats supportedJPEG XR, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Image stabilizer locationLens
Still image resolution(s)-
Digital zoom4 x
Optical zoom7.1 x
Extra/Smart zoom14.3 x
Focal length range6 - 42.8 mm
Maximum aperture number5.9
Minimum aperture number2
Maximum focal length (35mm film equiv)200 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto/Manual
Auto focusing (AF) modesSpot Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAuto, Manual
ISO sensitivity (max)12800
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed250 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@25fps, 1280x720@50fps, 1920x1080@25fps, 1920x1080@50fps, 640x480@25fps
Audio systemstereo
Memory slots1
Internal memory87 MB
Compatible memory cardsSD, SDHC, SDXC
Maximum memory card size64 GB
Field of view100 %
Display diagonal3 \
Vari-angle LCD displayNo
Display resolution (numeric)920000 pixels
Viewfinder typeElectronic
Viewfinder screen size0.2 \
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesChildren, Food, Night, Night landscape, Night portrait, Pet, Sports, Sunset, Landscape (scenery)
Image editingResizing
Photo effectsAntique, Black&White, Sepia, Skin tones
White balanceAuto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Shooting modesAperture priority, Manual, Program, Scene, Shutter priority
Camera playbackMovie, Single image, Slide show
Self-timer delay2, 10 s
Battery life (CIPA standard)250 shots
Product colorBlack
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 9.2AE, SILKYPIX® Developer Studio, Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth27.9 mm
Width102.5 mm
Height62.1 mm
Weight170 g
Weight (including battery)192 g
