Usage cautions and notes
VQT5A33
- 281 -
About charging the battery
The time required for charging varies depending on conditions of battery usage. Charging takes
longer at high or low temperatures and when the battery has not been used in some time.
Battery will be warm during charging and for some time thereafter.
Battery will run out if not used for long periods of time, even after being charged.
Do not leave any metal items (such as clips) near the contact areas of the power plug.
Otherwise, a fire and/or electric shocks may be caused by short-circuiting or the resulting heat
generated.
Frequently charging up battery is not recommended.
(Frequently charging battery reduces maximum usage time and can cause battery to expand.)
If available battery power is significantly reduced, battery is reaching end of lifespan. Please
purchase a new battery.
When charging:
Wipe dirt from the battery terminal with a dry cloth.
Keep at least 1 m (3.3 feet) away from AM radio (may cause radio interference).
Do not use a damaged or dented battery (especially connectors), e.g. by dropping (can cause
faults).
Do not peel off or scratch the covering on the battery.
Using a battery with a part of or all of its covering removed or broken may cause malfunction.
About AC adaptor (supplied)
Keep at least 1 m (3.3 feet) away from AM radio (may cause radio interference).
The AC adaptor (supplied) may generate whirring sounds when it is being used. This is not a
malfunction.
After use, be sure to disconnect the power supply device from the electrical outlet. (A very small
amount of current is consumed if it is left connected.)
Lens
Images may appear slightly white if lens is dirty (fingerprints, etc.). Turn the camera on, hold the
extracted lens barrel with your fingers, and gently wipe the lens surface with a soft, dry cloth.
Do not leave the lens exposed to direct sunlight.
Do not touch the lens barrier, as this may damage lens. Be careful when removing camera from
bag, etc.
When using a tripod or unipod
Do not apply excessive force or tighten screws when they are crooked. (This may damage the
camera, screw hole, or label.)
Ensure that the tripod is stable. (Refer to the tripod instructions.)
You may not be able to remove the card or the battery when using a tripod or unipod.

Table of Contents

Other manuals for Panasonic LUMIX DMC-LF1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-LF1 and is the answer not in the manual?

Panasonic LUMIX DMC-LF1 Specifications

General IconGeneral
Megapixel12.1 MP
Camera typeCompact camera
Sensor typeLive MOS
Image stabilizerYes
Image sensor size1/1.7 \
Image formats supportedJPEG XR, MPO, RAW
Supported aspect ratios1:1, 3:2, 4:3, 16:9
Maximum image resolution4000 x 3000 pixels
Image stabilizer locationLens
Still image resolution(s)-
Digital zoom4 x
Optical zoom7.1 x
Extra/Smart zoom14.3 x
Focal length range6 - 42.8 mm
Maximum aperture number5.9
Minimum aperture number2
Maximum focal length (35mm film equiv)200 mm
Minimum focal length (35mm film equiv)28 mm
Focus adjustmentAuto/Manual
Auto focusing (AF) modesSpot Auto Focus, Tracking Auto Focus
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modesAuto, Manual
ISO sensitivity (max)12800
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed250 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Power source typeBattery
Video resolutions640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supportedAVCHD, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Resolution at capture speed1280x720@25fps, 1280x720@50fps, 1920x1080@25fps, 1920x1080@50fps, 640x480@25fps
Audio systemstereo
Memory slots1
Internal memory87 MB
Compatible memory cardsSD, SDHC, SDXC
Maximum memory card size64 GB
Field of view100 %
Display diagonal3 \
Vari-angle LCD displayNo
Display resolution (numeric)920000 pixels
Viewfinder typeElectronic
Viewfinder screen size0.2 \
HDMI connector typeMicro
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modesChildren, Food, Night, Night landscape, Night portrait, Pet, Sports, Sunset, Landscape (scenery)
Image editingResizing
Photo effectsAntique, Black&White, Sepia, Skin tones
White balanceAuto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Shooting modesAperture priority, Manual, Program, Scene, Shutter priority
Camera playbackMovie, Single image, Slide show
Self-timer delay2, 10 s
Battery life (CIPA standard)250 shots
Product colorBlack
Cables includedUSB
Bundled softwarePHOTOfunSTUDIO 9.2AE, SILKYPIX® Developer Studio, Adobe Reader
Weight and Dimensions IconWeight and Dimensions
Depth27.9 mm
Width102.5 mm
Height62.1 mm
Weight170 g
Weight (including battery)192 g
