AMPLIFIER SECTION
Rated minimum sine wave RMS power output
20 Hz - 20 kHz both channels driven (with AES17 filter)
0.7 % total harmonic distortion 130 W per channel (6 Ω)
Total harmonic distortion
rated power at 20 Hz - 20 kHz 0.7 % (6 Ω)
Power output each channel driven at 20 Hz - 20 kHz
(with AES17 filter)
0.7 % total harmonic distortion
Front (L/R) 130 W (6 Ω)
Center 130 W (6 Ω)
Surround (L/R) 130 W (6 Ω)
Surround Back (L/R) 130 W (6 Ω)
Load impedance
Front (L/R)
A or B 4 to 8 Ω
A and B 6 to 8 Ω
BI-WIRE 4 to 8 Ω
Center 6 to 8 Ω
Surround (L/R) 6 to 8 Ω
Surround Back (L/R) 6 to 8 Ω
Frequency response
CD, AUX, TV, GAME, CABLE/SAT, VCR,
DVD RECORDER, BD/DVD PLAYER /
ANALOG 8CH IN, OPTION PORT 4 Hz to 40 kHz, ±2 dB
Input sensitivity and impedance
CD, AUX, TV, GAME, CABLE / SAT, VCR,
DVD RECORDER, BD/DVD PLAYER /
ANALOG 8CH IN, OPTION PORT 16 mV (200 mV, IHF'66) 22 kΩ
Subwoofer frequency response (-6 dB) 7 Hz to 200 Hz
S/N (IHF A)
CD, TV, BD/DVD PLAYER,
DVD RECORDER (Digital Input) 97 dB, IHF'66
Tone controls
BASS 50 Hz, +10 to -10 dB
TREBLE 20 kHz, +10 to -10 dB
Output voltage
DVD RECORDER 200 mV
Digital input (OPTICAL) 3
(COAXIAL) 1
HDMI Input (Corresponding Deep Color) 3
Output (Corresponding Deep Color) 1
This unit supports “HDAVI Control 3” function.
g
FM TUNER SECTION
Frequency range 87.9 to 107.9 MHz (200 kHz steps)
87.5 to 108.0 MHz (100 kHz steps)
Sensitivity 11.2 dBf (2 µV, IHF'58)
Total harmonic distortion
MONO 0.5 %
STEREO 0.7 %
S/N
MONO 73 dB
STEREO 67 dB
Alternate channel selectivity 65 dB
Antenna terminal 75 Ω (unbalanced)
g
AM TUNER SECTION
Frequency range 520 to 1710 kHz
g
OPTION PORT SECTION
An exclusive terminal for SH-PD10 (option) 1
g
VIDEO SECTION
Output voltage at 1 V input (unbalanced) 1±0.1 Vp-p
Maximum input voltage 1.5 Vp-p
Input/output impedance 75 Ω
Composite Video Input BD/DVD PLAYER, DVD RECORDER,
VCR, CABLE/SAT, GAME, AUX
Output DVD RECORDER, TV MONITOR
S-Video Input BD/DVD PLAYER, DVD RECORDER,
VCR, CABLE/SAT, GAME, AUX
Output DVD RECORDER, TV MONITOR
Component Video Input BD/DVD PLAYER, DVD RECORDER,
CABLE/SAT
Output TV MONITOR
g
GENERAL
Power supply AC 120 V, 60 Hz
Power consumption 150 W
Dimensions (W x H x D) 430 mm x 158.5 mm x 339 mm
(16-15/16" x 6-1/4" x 13-11/32")
Mass (Weight) Approx. 5 kg (11 lb.)
Operating temperature range 0°C to 40°C
(32°F to 104°F)
Operating humidity range 20% to 80% RH (no condensation)
Power consumption in standby mode: 0.7 W
Power consumption in HDMI off mode: 0.4 W
Notes:
1. Specifications are subject to change without notice.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
Specifications
