Panasonic SA-PM45E - Table of Contents; Channel

Beam source Semiconductor laser
Laser power CLASS 1
A
udio output (Disc)
Number of channels 2 Channel
Frequency response 20 Hz to 20 kHz (+1, -2 dB)
Wow and flutter Below measurable limit
Digital filter 8fs
D/A converter MASH (1 bit DAC)
n USB Section
Playable USB Storage Media
1. HDD
2. USB MP3 player/Digital audio player
3. USB Thumbdrives
Supported audio file format
MP3
USB memory port
Maximum current 500mA
Bit rate
MP3 32 kbps to 320 kbps
A
udio output (MP3)
Number of channels 2 channel
Frequency response (MP3) 20 Hz to 20 kHz
1 Safety Precautions
4
1.1. GENERAL GUIDELINES
4
1.2. Before Repair and Adjustment
5
1.3. Protection Circuitry
5
1.4. Safety Part Information
5
2 Prevention of Electro Static Discharge (ESD) to
Electrostatically Sensitive (ES) Devices
6
3 Precaution of Laser Diode
7
4 Handling Precautions For Traverse Deck
8
5 Handling the Lead free Solder
9
5.1. General description about Lead Free Solder (PbF)
9
6 Accessories
10
7 Operation Procedures
11
7.1. Main Unit Key Buttons Operation
11
7.2. Remote Control Key Buttons Operation
12
7.3. Disc Information
12
8 Self diagnosis and special mode setting
13
8.1. Service Mode Summary Table
13
8.2. Service Mode Table
13
8.3. Cassette Mechanism Self-Diagnostic Mode
19
8.4. Error Code Table
19
9 Assembling and Disassembling
21
9.1. Caution
21
n General
Power supply AC 230 V, 50 Hz
Power consumption 63 W
Dimensions (W x H x D) 164 mm x 227 mm x 314 mm
Mass 3.4 kg
Operating temperature range +5 to +35°C
Operating humidity range 5 to 90 % RH (no condensation)
Power consumption in standby
mode
0.6 W (approx.)
Notes :
1. Specifications are subject to change without notices. Mass and
dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
n System : SC-PM45E-K
Music center: SA-PM45E-K
Speaker: SB-PM45EG-K
n System : SC-PM45EG-K
Music center: SA-PM45EG-K
Speaker: SB-PM45EG-K
n System : SC-PM45EE-K
Music center: SA-PM45EE-K
Speaker: SB-PM45EG-K
n System : SC-PM45EG-S
Music center: SA-PM45EG-K
Speaker: SB-PM45EG-S
9.2. Disassembly flow chart
22
9.3. Main Parts Location Diagram
23
9.4. Disassembly of Side Panel (L / R)
24
9.5. Disassembly of Top Cabinet Unit
24
9.6. Disassembly of Deck Mechanism and Tape Eject P.C.B
24
9.7. Disassembly of CD Lid
25
9.8. Disassembly of Front Panel
26
9.9. Disassembly of USB P.C.B
27
9.10. Disassembly of Panel P.C.B, Headphone P.C.B & Music
Port P.C.B
28
9.11. Disassembly of Rear Panel
29
9.12. Disassembly of Main P.C.B
29
9.13. Replacement of the Power IC
29
9.14. Disassembly of Transformer P.C.B
30
9.15. Disassembly of CD Mechanism
30
9.16. Disassembly of Cassette Lid
31
9.17. Disassembly of Traverse Unit, Driving Gear, and Cam
Gear
32
9.18. Disassembly of deck mechanism
36
9.19. Handling of cassette tape jam
38
10 Service Positions
39
10.1. Check and Repair of Deck, Deck Mechanism & Tape Eject
P.C.B
39
CONTENTS
Page Page
2
SA-PM45E / SA-PM45EG / SA-PM45EE
