Panasonic SA-PM45E - 16 Notes of Schematic Diagram

(All schematic diagrams may be modified at any time with
the development of new technology)
Notes:
S900: STOP switch. (
/ -DEMO).
S901: PLAY switch (CD
/ ).
S902: TAPE switch (TAPE
).
S903: TUNER switch (TUNER/BAND).
S904: USB switch (USB
/ ).
S905: FF switch (
/FF/ ).
S906: REW switch (
/ REW / ).
S907: POWER switch (AC IN
).
S909: BASS/TREBLE switch.
S910: REC switch (
REC/ ).
S911: MPORT switch (MUSIC P.).
S912: OPEN/CLOSE switch (
).
S971: MODE switch.
S972: HALF switch.
S975: RECINH_F switch.
S1000: TAPE EJECT switch.
S7201: RESET switch.
VR900: VR Volume jog.
· Importance safety notice :
Components identified by
mark have special
characteristics important for safety.
Furthe rmore, special parts which have purposes of fire-
retardant (resistors), high-quality sound (capacitors), low-
noise (resistors), etc. are used.
When replacing any of components, be sure to use only
manufacturer´s specified parts shown in the parts list.
· Capacitor values are in microfarad(µF) unless specified
otherwise, F=Fara d, pF=Pico-Farad
Resistance values are in ohm(Ω), unless specified
otherwise, 1K=1,000Ω, 1M=1,000KΩ
· Voltage and Signal lines:
: +B Signal line
: -B Signal line
: CD-DA signal line
: CD signal line
: Main signal line
: AUX signal line
: FM/AM signal line
: Tape Playback signal line
: Tape Recording signal line
: USB signal line
16 Notes of Schematic Diagram
